Concrete Mixer Pump

Share

Concrete Mixer Pump is a multi function machine which combines the function of concrete mixer and concrete pump. It can produce and deliver concrete. The mixer can be drum mixer, twin-shaft mixer and planetary mixer.

World famous brands of main parts are used for our concrete mixer pump, such as: Korean Kawasaki oil pump, Italy Manuli hydraulic hose, Japanese OMRON PLC, USA Parket seal, France Schneider electrical elements etc.

The concrete mixer pump can be diesel powered or electricity powered. If you have power supply on job site, electricity powered concrete mixer pump can be shosen because it is more cost-saving.

Welcome to contact us for details and quotations.




  • Product Description
  • Main Features
  • Product Model
  • Application


Concrete Mixer With Pump Solutions


Concrete Mixer With Pump is a mobile construction machine which is capable of not only producing concrete, but also pumping it by effectively combining two separate kits into one kit with a truck-mounted mixer and pump. This is a sophisticated yet easy-to-use machine, as it is equipped with smart and intuitive electronic systems.

A concrete mixing pump is ideal equipment for conveying concrete in large construction projects. The cement mixing pump combines the production and conveying of concrete, which can realize the continuous conveying of concrete from site to site. Concrete mixing pumps make full use of pressure to transport concrete through pipes.

Concrete mixers and pumps can achieve rapid and continuous horizontal and vertical conveying of concrete, which will greatly improve the work efficiency of your construction projects.

Why do some concrete pumps need to be supplied with a concrete mixer?


A concrete pump cannot dispense concrete without the use of a concrete mixer. A concrete mixer will combine all the ingredients needed to produce high-quality concrete, ensuring it is in top condition and can be pumped smoothly directly to where it is needed. Where a concrete mixer is capable of producing concrete without a concrete pump, a concrete pump cannot perform its function without a concrete mixer.

Our company has concrete mixer pump for sale, welcome to contact.

How to find a reliable concrete mixer?


Construction sites without concrete pumps and mixers are hard to find.

It also goes to show that concrete mixer pumps are essential for building sturdy buildings, so it's important to invest in a reliable concrete mixer with a pump that fits your specifications.

So it is very important to find a reliable and reputable concrete mixer with pump supplier.


1. Our concrete mixer pump is composed of the following parts:


1) power system: diesel engine or electric motor;

2) concrete mixer: drum mixer, twin-shaft mixer or planetary mixer;

3) concrete pump;

4) concrete hopper;

5) concrete delivery pipe;

6) control system (remote control is available).




2. Factors we need to consider when we choose a concrete mixer pump:


1) concrete delivery capacity;

2) Max. aggregate size;

3) power supply; If there is no electricity supply on job site, diesel powered concrete mixer pump is needed; if there is electricity supply, we can use electricity powered concrete mixer pump because it is cheaper;

4) concrete slump. It's better that the concrete slump is over 100.




3. Details of our concrete mixer pump:


1) Diesel Concrete Mixer Pump

JBS30R Diesel Concrete Mixer PumpJBS40R Diesel Concrete Mixer PumpLHB40R Diesel Concrete Mixer Pump

Capacity: 15 m3/h

Diesel Engine Brand: Weifang

Diesel Engine Power: 66 kw

Concrete Mixer Type: Drum mixer

Capacity: 15 m3/h

Diesel Engine Brand: Weichai

Diesel Engine Power: 82 kw

Concrete Mixer Type: Drum mixer

Capacity: 22.5 m3/h

Diesel Engine Brand: Weichai

Diesel Engine Power: 82 kw

Concrete Mixer Type: Planetary mixer

Concrete Mixer PumpConcrete Mixer PumpConcrete Mixer Pump


ModelJBS30RJBS40RLHB40R
Production Capacity (m3/h)151522.5
Concrete Mixer TypeDrum mixerDrum mixerPlanetary mixer
Feeding Capacity of Mixer (L)5605601200
Discharging Capacity of Mixer (L)350350750
Max. Pumping Pressure (Mpa)101010
Diesel Engine BrandWeifangWeichaiWeichai
Diesel Engine Power (kw)668282
Max. Delivery Distance (V/H) (m)80/30080/30080/300
Overall Size (mm)5000*1500* 18005500*2300* 31503800*2200* 2100
Total Weight (kg)450060005600


2) Electric Concrete Mixer Pump

JBS30 Electric Concrete Mixer PumpJBS40 Electric Concrete Mixer PumpLHB40 Electric Concrete Mixer Pump

Capacity: 15 m3/h

Motor Brand: Rongcheng

Motor Power: 37 kw

Concrete Mixer Type: Drum mixer

Capacity: 15 m3/h

Motor Brand: Rongcheng

Motor Power: 45 kw

Concrete Mixer Type: Drum mixer

Capacity: 22.5 m3/h

Motor Brand: Rongcheng

Motor Power: 45kw

Concrete Mixer Type: Planetary mixer

Concrete Mixer PumpConcrete Mixer PumpConcrete Mixer Pump



ModelJBS30JBS40LHB40
Production Capacity (m3/h)151522.5
Concrete Mixer TypeDrum mixerDrum mixerPlanetary mixer
Feeding Capacity of Mixer (L)5605601200
Discharging Capacity of Mixer (L)350350750
Max. Pumping Pressure (Mpa)101010
Motor BrandRongchengRongchengRongcheng
Motor Power (kw)374545
Max. Delivery Distance (V/H) (m)80/30080/30080/300
Overall Size (mm)5000*1500* 18004200*2300* 31503800*2200* 2100
Total Weight (kg)400045004800


3) Mini concrete mixer pump (diesel or electric type are all available)


Concrete Mixer Pump

Concrete Mixer Pump


ModelJBS10
Production Capacity (m3/h)8
Concrete Mixer TypeDrum mixer
Feeding Capacity of Mixer (L)300
Discharging Capacity of Mixer (L)200
Max. Pumping Pressure (Mpa)10
Diesel engineYANMAR
Engine Power (kw)30
Max. Delivery Distance (V/H) (m)80/300
Overall Size (mm)4100*2200* 2250
Total Weight (kg)3800




4. Special concrete mixer pump


1) concrete pump with aggregate batching machine ( In this way, we can solve the problem of concrete formula accuracy for single concrete mixer pump)


Concrete Mixer Pump

Concrete Mixer Pump

Concrete Mixer Pump

Concrete Mixer Pump


2) concrete pump with twin-shaft mixer (In this way, we can get higher concrete production capacity and better raw materials mixing performance)


Concrete Mixer Pump
